Cooling-Thermomixer MKR 13

<< Back \| Lab Equipment			Item #MKR 13

Image #1.

Cooling-Thermomixer MKR 13

Thermo Shaker MKR 13 is working on the basis of Smart Control

- 30 program steps and temperature curves programable
- Turning direction changeable by software
- Timer
- Short-mix function
- Interval shaking with snip effect

Select the one suitable for you from more than 30 different exchangeable blocks for the use of micro test tubes, test tubes, centrifugal tubes, cuvettes or PCR-plates, microtiter or Deep-Well plates.

Temperature work range		Amb. -16°C until +100°C
Temperature adjustable range		-10°C until +105°C
Accuracy / Resolution		+/- 0,1°C / 0,1°C
Average heating time		up to +40°C: approx. 6°C/ min
		from 41°C: approx. 5°C/ min
Medium cooling time		up to +20°C: approx. 7°C/min
		below +20°C: approx. 3°C/ min
Shaking frequency		200 ? 1.500 1/min
Orbit		3 mm orbital
Dimensions (W x D x H)		220 x 330 x 125 mm
Capacity		1 thermoblock
Weight (with block / blocks)		10 kg
Electrical heating- / cooling-power		120 W
Electrical supply		115 V / 230 V, 50-60 Hz
